Only for professionals

DIN 6796

Conical spring washers for threaded connections
Material: Spring steel | Surface: mechanically zinc-plated, thick-film passivated (VZD)

Diameter (d)

For further information please contact us.

Description

Read on Hide
DIN 6796 | steel | spring steel | zinc-plated, thick-film passivated | Cr(VI) - free
<
Surface (VZD): Mechanically galvanized, passivated, min. 8μm | corrosion resistance to DIN EN ISO 9227 | red rust 144h | defined coefficient of friction μ(total) = 0.12 - 0.18 for high-strength screws (≥ 8.8)

>*The verification of the mentioned minimum requirements is carried out according to the test conditions of ISO/CD 4042:2016, galvanic coatings for fasteners. For dimensions < M5, the above values may deviate downwards.

technical details

Read on Hide
Application Joining by bolt, joining by stud, joining by screw
Cr(VI) Note Cr(VI)-free
Form Round
Installation method Assembly by hand
Material Spring steel
Risk hydrogen embrittlement
RoHs conformal
Surface mechanically zinc-plated, thick-film passivated (VZD)

Downloads

You can download CAD-files from our catalog on partcommunity: To Böllhoff partcommunity
Title Language Version File Download
Böllhoff bulletin: Changeover to Cr6+-free protective zinc layers for fasteners English 1622/15.02 894.98 KB / PDF
Data sheet: Technical information and dimensions of the product English 04/2021 114.21 KB / PDF
Fastening and assembly technology: Products and services English 1180/21-V1-EN 8.79 MB / PDF
VZD – the Cr(VI)-free alternative: Sustainable surface protection from Böllhoff English 8045/17.02 212.24 KB / PDF
